HERO AND DETAIL SHOTS

Hero Shot

The hero shot captures the dominance of the building, reflect on both clients; Auto Fabrica and Off-White. It also seizes the texture used for the display section of the building. This is an important aspect to capture as the concept behind the texture is "harmonious" and is something that should be understood before entering the building.

Detail Shot

The detail shots reflects on the concept of "revealing". Shown in the image is a row of beams down the ramp and also to left of the image the sculptured glass that surrounds the stairs leading to Off-White. Both of these features allow for any work being taken to the showroom to be almost concealed for a big reveal.

ANIMATION VIDEOS

18 SKETCHES|

36 TEXTURES

Assessment Part One:The Stair Concept Model

3D Model Design

The model produced through SketchUp Pro was carefully constructed to represent the overall concept of the structure; unveiling. This was produced through stair designs that either shadowed the produced as its brought from the studio (Off White) or broadcasting the product once its ready for display (Auto Fabrica).

Staircase Sections

Short section Off White

_________________________________________________________________________

Long Section Off White

_________________________________________________________________________






Short Section Auto Fabrica




_________________________________________________________________________

Long Section Auto Fabrica

Sketched Scheme w/ stair sections

Above Ground Stair:

Short Section

Above Ground Stair:

Long Section

Under Ground Stair:

Short Section

Under Ground Stair:

Long Section
